IR relay-receiver for blind white - 20173.B

Pdf
Vimar - 20173.B - IR relay-receiver for blind white
Vimar - 20173.B - IR relay-receiver for blind white

20173.B
Wiring devices / Traditional wiring devices / EIKON / Devices

IR relay-receiver for blind white
Infrared receiver with 4 A 230 V~ relay output for roller blinds, control with built-in push buttons, 01849 remote control or from peripheral NO push buttons, mono-or-bistable mode, visible in darkness, supply voltage 230 V~ 50-60 Hz, white - 2 modules

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Drawings

view encumbered art. 20173.B
PNG DXF
rear view art. 20173.B
PNG DXF
3D view art. 20173.B
PNG DXF
Class group
Domestic switching devices
Class
Electronic insert for domestic switching devices
Model
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Radio-controlled
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
White
RAL-number (similar)
9016
Transparent
No

00. CE Marking - EU

01. IMQ - Italy

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352316188
1 NR
6x5.4x5.3 [cm]
74.93 [g]
Barcode Qty 5 NR
8007352316195
5 NR
17.2x13.1x6 [cm]
435 [g]
