Two 2P+E15A USA+SASO SICURYoutlets white - 20243.B

Pdf
Vimar - 20243.B - Two 2P+E15A USA+SASO SICURYoutlets white
Vimar - 20243.B - Two 2P+E15A USA+SASO SICURYoutlets white
20243.B

Eikon white / Devices / Other standards socket outlets

Two 2P+E15A USA+SASO SICURYoutlets white
Double 2P+E 15 A 127 V~ SICURY socket outlet, American and Saudi Arabian standards, white - 3 modules

Product Status
3 - Active

Drawings

view encumbered art. 20243.B
PNG DXF
rear view art. 20243.B
PNG DXF
3D view art. 20243.B
PNG DXF
Class group
Domestic switching devices
Class
Socket outlet
Model
American National Standard
With built-in USB power supply
No
Number of units
2
Number of modules (module system)
3
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Screwed terminal
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9016
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Matt
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
15 A
Nominal voltage
127 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
67,50 mm
Height of device
49,00 mm
Depth of device
35,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

29. QCERT - Colombia

37. Marking - Morocco

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352314191
1 NR
5.3x3.9x7.6 [cm]
59.8 [g]
Barcode Qty 20 NR
8007352314207
20 NR
28.1x13.1x11.3 [cm]
1,305.87 [g]
