TV-RD-SAT through-line outlet grey - 20300.10

Pdf

20300.10
Wiring devices / Traditional wiring devices / EIKON / Devices

TV-RD-SAT through-line outlet grey
Coaxial TV-RD-SAT 5-2400 MHz socket outlet, through-line, with male connector, connection attenuation 10 dB, grey

Product Status
3 - Active

Drawings

Class group
Antenna and satellite technique
Class
Antenna socket box
Model
Loop-through socket
Cover
None
Tap loss at 860 MHz
10,60 dB
Tap loss at 2150 MHz
9,90 dB
Number of outlets
1
Through loss at 860 MHz
2,20 dB
Through loss at 2150 MHz
3,40 dB
Suitable for remote power supply
No
Type of fastening
Snap mounting (engagement)
Colour
Grey
RAL-number (similar)
7024
Material
Plastic

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

43. UKCA mark - Great Britain

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352249127
1 NR
4.1x2.8x5.3 [cm]
49.8 [g]
Barcode Qty 20 NR
8007352249134
20 NR
21.4x11.6x6 [cm]
1,053 [g]
Barcode Qty 200 NR
8007352634794
200 NR
30.5x25.5x22.5 [cm]
10,870 [g]
