TV-FM-SAT single-conn. 3outs Next - 20303.N

Pdf
20303.N

Eikon Next / Devices / 3-output TV-RD-SAT socket outlets

TV-FM-SAT single-conn. 3outs Next
Coaxial TV-FM radio-SAT 5-2400 MHz socket outlet, single connection, demix, 3 outputs with TV male and female FM radio and F-type (SAT) connectors, connection attenuation 1 dB, Next - 2 modules. Allows the passage of d.c. current and control signals (24 V 500 mA max) through the female connector

Product Status
3 - Active

Class group
Antenna and satellite technique
Class
Antenna socket
Model
End socket
Cover
None
Tap loss at 860 MHz
1,80 dB
Tap loss at 2150 MHz
1,30 dB
Number of outlets
3
Suitable for remote power supply
Yes
Frequency
5 - 2400 MHz
Type of fastening
Snap mounting (engagement)
Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352395343
1 NR
5.1x4.3x5.3 [cm]
82.5 [g]
Barcode Qty 5 NR
8007352395350
5 NR
14.4x11.6x6 [cm]
460 [g]
