1P+N C6 120-230V CB Next - 20405.06.N

20405.06.N

Eikon Next / Devices / Current breaker switches (CBs)

1P+N C6 120-230V CB Next
1P+N C 6 circuit breaker, supply voltage 120-230 V~ 50-60 Hz, breaking capacity 1500 A, Next

Product Status
3 - Active

Class group
Circuit breakers and fuses
Class
Miniature circuit breaker (MCB)
Release characteristic
C
Number of poles (total)
2
Number of protected poles
1
Rated current
6 A
Rated voltage
230 v
Rated short-circuit breaking c
1,50 kA
Voltage type
AC
Frequency
50 - 60 HZ
Current limiting class
1
Suitable for flush-mounted ins
Yes
Concurrently switching N-neutr
Yes
Over voltage category
3
Width in number of modular spa
1
Built-in depth
38,00 mm
Degree of protection (IP)
IP40
Minimum order quantity: 5 NR

Barcode

8007352286344
1 NR
6x2.8x5.3 [cm]
55 [g]
8007352286351
5 NR
14.2x6.7x5.9 [cm]
305.47 [g]
