Domotic IR transmitter grey - 20584.1

Pdf
Vimar - 20584.1 - Domotic IR transmitter grey
Vimar - 20584.1 - Domotic IR transmitter grey

20584.1
Smart systems&products / By-me Plus / EIKON / Devices

Domotic IR transmitter grey
Interface for By-me commands transmission to IR receiver, complete with 3 m of cable, grey

Product Status
3 - Active

Class group
Installation bus systems
Class
Interface for bus system
Bus system KNX
No
Bus system KNX-RF (Radio Frequent)
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Model
Other
Mounting method
Flush-mounted
Width in number of modular spacings
1
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Grey
RAL-number (similar)
7024
Transparent
No
With bus connection
Yes
With LED indication
Yes
Degree of protection (IP)
IP30

00. CE Marking - EU

19. NOM - Mexico

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352512627
1 NR
11.2x9.6x9.8 [cm]
108.8 [g]
Question: Can I connect the IR interface 14584.1//20584.1 to the BUS line of the sound system?
Answer: No, this device must be connected to the home automation BUS line and configured in a group with the sound system menu.
