Rolling shutter IoT connected mechanism
View Wireless connected electronic control device for 1 roller shutter with slat orientation and change-over relay output for cosφ 0,6 motor 2 A 100-240 V~ 50/60 Hz, local or remote control, double technology with Bluetooth® wireless technology 5.0 standard for the realization of View Wireless mesh system andZigbee 3.0 standard, 1 input for external push button to recall a scenario, favourite position recall function, RGB LED visible in darkness with brightness control, 100-240 V 50/60 Hz power supply, to be completed with two interchangeable 1-module Eikon half-buttons

  • Compatible with Alexa, Google Home and IFTTT, using the dedicated gateway or Zigbee hub

Product Status
3 - Active

You may also be interested in

Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
1
Number of poles
1
Nominal voltage
230 v
Rated current
5,00 A
With lighting
Yes
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7024
Transparent
No
Label space/information surface
Yes
Imprint
None
Suitable for degree of protection (IP)
IP40
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
46,90 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352628588
1 NR
6x5.4x5.2 [cm]
52.2 [g]
Barcode Qty 60 NR
8007352628595
60 NR
37.5x30x13.5 [cm]
3,912 [g]
Question: With which physical devices can I activate a scenario control in the connected system?
Answer: Mechanical push buttons connected to connected devices which envisage the function or using the radio control 03925.
Question: How many Energy meters art.02963 can I install in a Wireless system?
Answer: Each connected system allows a maximum of 2 meters art.02963.
Question: To control a roller shutter via App, do I only need the module code 14594-16494-19594-20594 with the gateway art. 14597-16497-19597-20597?
Answer: The control is designed to control the roller shutter/slat using the on-board keys and via a wireless connection. The device has the possibility of being controlled with two different radio standards (exclusive to one another): Bluetooth mesh (default) or Zigbee. The Bluetooth mesh network implies the presence of gateway 20597-19597-16497-14597 and management will occur via the VIEW App, whereas when using Zigbee technology a Zigbee 3.0 gateway is required (such as Amazon Echo Plus, Echo Show or Echo Studio) with related management via Amazon App.
Question: Is code 14594-16494-19594-20594 suitable for replacing the centralised opening control of all roller shutters?
Answer: The device is fitted with an on-board actuator for the management of a single roller shutter.
Question: On a system where I have installed the connected control for roller shutters art.14594-16494-19594-20594, can I leave secondary points with the traditional roller shutter control?
Answer: No, each roller shutter motor must be controlled by a single control art.14594-16494-19594-20594; in the event that you need a centralised control (to raise and lower all roller shutters), you need to exploit input P, on board the individual connected controls, connecting it with a control such as art.14062-2062-19062 and creating two dedicated scenarios in the Wireless system.
Question: After I have set the device as Zigbee, how can I reset the device to Bluetooth mode?
Answer: The procedure allowing the conversion of the operating mode/technology on the product in question can be found inside the ˝VIEW Wireless˝ App in the menu: ˝Actions -> Manage device˝.
