Plate 10in aluminium - 21665.11

Pdf
Vimar - 21665.11 - Plate 10in aluminium
Vimar - 21665.11 - Plate 10in aluminium

21665.11
Smart systems&products / By-me Plus / Shared components / Cover plates

Plate 10in aluminium
10 in cover plate, anodized aluminium

Product Status
3 - Active

Drawings

view encumbered art. 21665.11
PNG DXF
rear view art. 21665.11
PNG DXF
3D view art. 21665.11
PNG DXF
Class group
Domestic switching devices
Class
Cover frame for domestic switching devices
Number of units
1
Mounting direction
Horizontal and vertical
Number of units horizontal
1
Number of units vertical
1
Number of modules horizontal (module system)
1
Number of modules vertical (module system)
1
With mounting grid
Yes
Suitable for subfloor installation duct box
Yes
Suitable for wall duct
Yes
Suitable for built-in installation
Yes
Label space/information surface
Yes
Material
Other
Material quality
Aluminium
Halogen free
Yes
Surface protection
Anodised
Surface finishing
Matt
Colour
Aluminium
RAL-number (similar)
9006
Transparent
No
With hinged lid
No
Degree of protection (IP)
IP00
Type of fastening
Clamp mounting
Width
345,00 mm
Height
250,00 mm
Depth
16,20 mm
Built-in width
345,00 mm
Built-in height
250,00 mm
Diameter bore hole (opening)
0 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352424067
1 NR
40.5x30x7 [cm]
1,170 [g]
