KNX thermostat STAR 2M white diamondCode 21814.S.70
- 21814.S.70
- Smart systems&products / KNX / EIKON / Devices
- KNX thermostat STAR 2M white diamond
- Touch screen thermostat for room temperature control (heating and air conditioning), KNX standard home automation system, configurable STAR control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with actuator with proportional analogue outputs to make a class V modulating room thermostat (contribution 3%), 1 input for electronic temperature sensor 20432, 19432 or 14432 or wired temperature sensor 02965.1, 1 programmable digital input, RGB LED backlighting, white diamond - 2 modules
- Product Status
- 3 - Active
Sheets, Manuals, Documentation
Product Software
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Room temperature controller for bus system
Room temperature controller for bus system
Bus system KNX
Yes
Yes
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequency bidirectional
No
No
Assembly arrangement
Control element
Control element
Mounting method
Flush-mounted
Flush-mounted
With local operation
Yes
Yes
With anti-theft/dismantling protection
No
No
With LED indication
Yes
Yes
With display
Yes
Yes
Material
Glass
Glass
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Glossy
Glossy
Colour
White
White
RAL-number (similar)
9016
9016
Transparent
No
No
Manual set point setting
Yes
Yes
Presence button
No
No
Parallel-service possible
No
No
Degree of protection (IP)
IP40
IP40
With bus connection
Yes
Yes
Class of the temperature control
V
V
00. CE Marking - EU
37. Marking - Morocco
Minimum order quantity: 1 NR
Barcode
8007352659612
1 NR
15.5x15x6 [cm]
310 [g]
