KNX thermostat STAR 2M black diamond - 21814.S.76

Pdf
Vimar - 21814.S.76 - KNX thermostat STAR 2M black diamond
Vimar - 21814.S.76 - KNX thermostat STAR 2M black diamond
21814.S.76

Eikon TACTIL / Systems / KNX

KNX thermostat STAR 2M black diamond
Touch screen thermostat for room temperature control (heating and air conditioning), KNX standard home automation system, configurable STAR control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with actuator with proportional analogue outputs to make a class V modulating room thermostat (contribution 3%), 1 input for electronic temperature sensor 20432, 19432 or 14432 or wired temperature sensor 02965.1, 1 programmable digital input, RGB LED backlighting, black diamond - 2 modules

Product Status
3 - Active

Class group
Installation bus systems
Class
Room temperature controller for bus system
Bus system KNX
Yes
Bus system KNX radio
No
Bus system radio frequent
No
Bus system LON
No
Bus system Powernet
No
Other bus systems
Other
Radio frequent bidirectional
No
Assembly arrangement
Control element
Mounting method
Flush mounted (plaster)
With local operation
Yes
With anti-theft/dismantling protection
No
With LED indication
Yes
With display
Yes
Material
Glass
Material quality
Thermoplastic
Surface protection
Untreated
Surface finishing
Glossy
Colour
Black
RAL-number (similar)
9005
Transparent
No
Manual set point setting
Yes
Presence button
No
Parallel-service possible
No
Degree of protection (IP)
IP40
With bus connection
Yes
Class of the temperature control
V

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352659513
1 NR
15.5x15x6 [cm]
310 [g]
