1P 10AX 2-way switch Vintage nickel - 22004.11

Pdf

22004.11
Wiring devices / Traditional wiring devices / EIKON / Devices

1P 10AX 2-way switch Vintage nickel
1P 10AX 2-way switch Vintage nickel. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Metallic
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
7048
Label space/information surface
Yes
Illumination
No
Function lighting
Control and orientation
Type of lighting
Other
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device height
48,80 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

19. NOM - Mexico

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352620605
1 NR
5.1x2.7x6.5 [cm]
33.4 [g]
Barcode Qty 10 NR
8007352620612
10 NR
14.5x11x7.4 [cm]
383.5 [g]
