Vimar - 22004.82 - 1P 10AX 2-way switch Vintage gold

22004.82
Wiring devices / Traditional wiring devices / EIKON / Devices

1P 10AX 2-way switch Vintage gold
1P 10AX 2-way switch Vintage gold. Max 100 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Drawings

view encumbered art. 22004.82

PNG DXF

rear view art. 22004.82

PNG DXF

3D view art. 22004.82

PNG DXF

Class group
Domestic switching devices

Class
Installation switch

Wiring system
Two-way switch

Method of operation
Other

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
1

Push button switch
Yes

Number of rockers
1

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

With mounting plate
No

Material
Plastic

Material quality
Other

Surface protection
Metallic

Surface finishing
Glossy

Colour
Gold

RAL-number (similar)
1004

Label space/information surface
Yes

Lighting
No

Function lighting
Control and orientation

Type of lighting
Other

Nominal voltage
250 V

Rated current
10,00 A

Monitoring contact
No

Connection type
Screwed terminal

Washing machine switch
No

Device height
48,80 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

11. SNI-SUCOFINDO Indonesia

13. SNI-MGI - Indonesia

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

8007352620803

1 NR

5.1x6.5x2.7 [cm]

33.3 [g]

8007352620810

10 NR

14.5x11x7.4 [cm]

381.3 [g]
