Vimar - 22061.01 - 2P 10A 2-way push button Vintage white

22061.01

Eikon EXÉ / Devices / Vintage and Flat devices

2P 10A 2-way push button Vintage white
2P 10A 2-way push button Vintage white

Product Status
3 - Active

Drawings

view encumbered art. 22061.01

PNG DXF

rear view art. 22061.01

PNG DXF

3D view art. 22061.01

PNG DXF

Class group
Domestic switching devices

Class
Push button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
2

Number of modules (module system)
100

Number of poles
2

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush-mounted

Type of fastening
Engage (snap)

Material
Metal

Material quality
Other

Surface protection
Lacquered

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Transparent
No

Label space/information surface
Yes

Device height
48,80 mm

Device depth
63,10 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

8007352620520

1 NR

5.1x6.5x2.7 [cm]

46.8 [g]

8007352620537

10 NR

14.5x11x7.4 [cm]

514.1 [g]
