2P 10A 2-way push button Vintage nickel - 22061.11

Pdf
Vimar - 22061.11 - 2P 10A 2-way push button Vintage nickel
Vimar - 22061.11 - 2P 10A 2-way push button Vintage nickel
22061.11

Eikon EXÉ / Devices / Vintage and Flat devices

2P 10A 2-way push button Vintage nickel
2P 10A 2-way push button Vintage nickel

Product Status
3 - Active

Drawings

view encumbered art. 22061.11
PNG DXF
rear view art. 22061.11
PNG DXF
3D view art. 22061.11
PNG DXF
Class group
Domestic switching devices
Class
Push-switch button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
1
Number of poles
2
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
Material
Metal
Material quality
Other
Surface protection
Metallic
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
7048
Transparent
No
Label space/information surface
Yes
Height of device
48,80 mm
Depth of device
63,10 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

15. CCC - China

36. ISI - India

37. Marking - Morocco

92. RoHS UAE

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352620643
1 NR
5.1x6.5x2.7 [cm]
47.3 [g]
Barcode Qty 10 NR
8007352620650
10 NR
14.5x11x7.4 [cm]
517.5 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
