2P 10A 2-way push button Vintage bronze - 22061.12

Pdf

Vimar - 22061.12 - 2P 10A 2-way push button Vintage bronze

22061.12

Eikon EXÉ / Devices / Vintage and Flat devices

2P 10A 2-way push button Vintage bronze
2P 10A 2-way push button Vintage bronze

Product Status
3 - Active

Drawings

view encumbered art. 22061.12

PNG DXF

rear view art. 22061.12

PNG DXF

3D view art. 22061.12

PNG DXF

Class group
Domestic switching devices

Class
Push-switch button

Assembly arrangement
Modular device for domestic switching devices

Model
Single push button

Method of operation
Push button

Number of rockers
2

Number of modules (module system)
1

Number of poles
2

Rated current
10,00 A

With lighting
No

Feedback-signal contact
No

Mounting method
Flush mounted (plaster)

Type of fastening
Engage (snap)

Material
Metal

Material quality
Other

Surface protection
Lacquered

Surface finishing
Matt

Colour
Bronze

RAL-number (similar)
7008

Transparent
No

Label space/information surface
Yes

Height of device
48,80 mm

Depth of device
63,10 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

8007352620780

1 NR

5.1x2.7x6.5 [cm]

46.7 [g]

8007352620797

10 NR

14.5x11x7.4 [cm]

514.5 [g]
