2P 10A 2-way push butt.Vintage satingold - 22061.88

Pdf
Vimar - 22061.88 - 2P 10A 2-way push butt.Vintage satingold
Vimar - 22061.88 - 2P 10A 2-way push butt.Vintage satingold

22061.88
Wiring devices / Traditional wiring devices / EIKON / Devices

2P 10A 2-way push butt.Vintage satingold
2P 10 A 250 V~ Vintage 2-way push button (6 terminals), with central OFF position, satin-finish gold

Product Status
3 - Active

Drawings

view encumbered art. 22061.88
PNG DXF
rear view art. 22061.88
PNG DXF
3D view art. 22061.88
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
100
Number of poles
2
Nominal voltage
230 V
Rated current
10,00 A
With lighting
No
With signal lamp
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Metal
Material quality
Brass
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Gold
RAL-number (similar)
1035
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
44,80 mm
Device depth
63,10 mm

00. CE Marking - EU

01. IMQ - Italy

09. VDE - Germany

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

19. NOM - Mexico

20. IQC - Argentina

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352655393
1 NR
5.1x6.5x2.7 [cm]
46.8 [g]
Barcode Qty 10 NR
8007352655409
10 NR
14.5x11x7.4 [cm]
516.2 [g]
