30411.166G
Wiring devices / Traditional wiring devices / LINEA / Devices
1P+N C16 RCBO 120-230V 6mA black
1P+N C 16 residual current breaker with overcurrent protection (RCBO), 120-230 V~ 50-60 Hz, IΔn 6 mA, breaking capacity 3000 A, black - 2 modules
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Circuit breakers and fuses
Circuit breakers and fuses
Class
Earth leakage circuit breaker
Earth leakage circuit breaker
Number of poles (total)
2
2
Number of protected poles
1
1
Rated voltage
230 V
230 V
Rated impulse withstand voltage Uimp
3 kV
3 kV
Rated current
16 A
16 A
Rated fault current
16 A
16 A
Leakage current type
A
A
Current limiting class
1
1
Rated short-circuit breaking capacity according to EN 61009
3 kA
3 kA
Rated short-circuit breaking capacity according to IEC 60947-2
3 kA
3 kA
Rated short-circuit breaking capacity Icn according to EN 61009-1
3,00 kA
3,00 kA
Surge current capacity
3,00 kA
3,00 kA
Voltage type
AC
AC
Frequency
50/60 Hz
50/60 Hz
Release characteristic
C
C
Concurrently switching neutral conductor
Yes
Yes
With interlocking device
No
No
Overvoltage category
3
3
Built-in depth
43,80 mm
43,80 mm
Flush-mounted installation
Yes
Yes
Anti-nuisance tripping version
No
No
Degree of protection (IP)
IP40
IP40
Connectable conductor cross section multi-wired
1,50 - 4,00
1,50 - 4,00
Minimum order quantity: 1 NR
Barcode
8007352740938
1 NR
6x5.4x5.2 [cm]
97.96 [g]
8007352740945
10 NR
28.1x13.1x6 [cm]
1,064 [g]
