Dial thermostat 100-240V 2M whiteCode 30440.B
- 30440.B
- Wiring devices / Traditional wiring devices / LINEA / Devices
- Dial thermostat 100-240V 2M white
- Dial thermostat with relay output 5(2) A 240 V~, heating and air conditioning in ON/OFF MODE, class I temperature control device (contribution 1%), white LED backlighting with brightness control, 100-240 V 50/60 Hz power supply, to be completed with cover plate, white - 2 modules
- Simple programming
- Suitable for all heating or cooling systems
- Maximum simplicity thanks to the large knob
- Hotkeys are designed for quick interaction
- Product Status
- 3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Stats, switches and controllers
Stats, switches and controllers
Class
Room thermostat
Room thermostat
Model
On/Off
On/Off
Type of power supply
230 V AC
230 V AC
Connection
2-wire
2-wire
With receiver
No
No
Measuring range
0 - 40 °C
0 - 40 °C
External sensor
No
No
Thermal feedback
Parallel
Parallel
Control characteristic
Other
Other
Suitable for heating
Yes
Yes
Number of heater outputs
1
1
Suitable for cooling
Yes
Yes
Number of cooler outputs
1
1
Differential value
0,30 - 0,31 k
0,30 - 0,31 k
Adjustable differential
No
No
Temperature readable
Yes
Yes
With sound indicator
No
No
Sensor/feeler type
Resistance sensor
Resistance sensor
Mounting method
Flush-mounted
Flush-mounted
Number of modules (module system)
2
2
With display
Yes
Yes
Operation
Turn
Turn
With tap water circuit
No
No
Contact type
Normally open contact (NO)
Normally open contact (NO)
Max. contact voltage
230 V
230 V
Max. contact load
5 A
5 A
Degree of protection (IP)
IP20
IP20
Degree of protection (NEMA)
Other
Other
Explosion-proof
No
No
Colour
White
White
RAL-number
9016
9016
Height
52,80 mm
52,80 mm
Width
44,80 mm
44,80 mm
Depth
41,70 mm
41,70 mm
Diameter
0,00 mm
0,00 mm
Class of the temperature control
I
I
Compatible with Apple HomeKit
No
No
Compatible with Google Assistant
No
No
Compatible with Amazon Alexa
No
No
IFTTT support available
No
No
00. CE Marking - EU
00. CE Marking - EU
37. Marking - Morocco
Minimum order quantity: 1 NR
Barcode
8007352695917
1 NR
6x5.4x5.2 [cm]
69.2 [g]
8007352695924
10 NR
28.1x13.1x6 [cm]
780.2 [g]
8007352695931
120 NR
40x30x27 [cm]
9,839 [g]
