Home autom.dial thermostat 2M white - 30471.B

Pdf
Vimar - 30471.B - Home autom.dial thermostat 2M white
Vimar - 30471.B - Home autom.dial thermostat 2M white

30471.B
Smart systems&products / By-me Plus / LINEA / Devices

Home autom.dial thermostat 2M white
Home automation system dial thermostat for room temperature control (heating and air conditioning), 2- and 4-pipe system management, 3-speed and proportional fan coil control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with actuator with proportional analogue outputs 01466.1 to make a class V modulating room thermostat (contribution 3%), 1 input for wired temperature sensor 02965.1, white LED backlighting, white - 2 modules.

Product Status
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
Other
Connection
2-wire
With receiver
No
Measuring range
0 - 40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
Yes
Number of cooler outputs
1
Differential value
0,10 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Max. contact voltage
29 V
Max. contact load
0 A
Degree of protection (IP)
IP20
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
White
RAL-number
9016
Height
52,80 mm
Width
44,80 mm
Depth
41,70 mm
Diameter
0 mm
Class of the temperature control
V
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352689282
1 NR
6x5.4x5.2 [cm]
60.8 [g]
Barcode Qty 10 NR
8007352689299
10 NR
28.1x13.1x6 [cm]
696.4 [g]
Barcode Qty 120 NR
8007352689305
120 NR
38.5x29x30 [cm]
8,833 [g]
