30474.G
Smart systems&products / By-me Plus / LINEA / Devices
Relay actuator 16A sensor black
Actuator with relay output 16 A 230 V ~ 50 Hz with integrated current sensor, black - 2 modules
Product Status
3 - Active
Sheets, Manuals, Documentation
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Switch actuator for bus system
Switch actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
No
No
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
None
None
Radio frequency bidirectional
Yes
Yes
Mounting method
Flush-mounted
Flush-mounted
Width in number of modular spacings
1
1
Local operation/hand operation
Yes
Yes
With LED indication
Yes
Yes
Number of digital inputs
0
0
Suitable for C-load
Yes
Yes
Max. number of switching contacts
1
1
Max. switching current
16 A
16 A
Rated current
16 A
16 A
Rated operating voltage
230,00 - 230,01 V
230,00 - 230,01 V
Different phases connectable
No
No
With bus connection
Yes
Yes
Bus module detachable
No
No
Modular expandability
No
No
Degree of protection (IP)
IP40
IP40
Minimum order quantity: 1 NR
Barcode

8007352688919
1 NR
6x5.4x5.2 [cm]
61.8 [g]

8007352688926
10 NR
28.1x13.1x6 [cm]
618 [g]
