Home automation temperature probe black - 30478.G

Pdf
Vimar - 30478.G - Home automation temperature probe black
Vimar - 30478.G - Home automation temperature probe black

30478.G
Smart systems&products / By-me Plus / LINEA / Devices

Home automation temperature probe black
Temperature probe for room temperature control (heating and air conditioning), 2- and 4-pipe system management, 3-speed and proportional fan coil control, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, 1 input for flush mounting or wired temperature NTC sensor, for By-me home automation system, can be interfaced with actuator with proportional analogue outputs 01466 to make a class V modulating room thermostat (contribution 3%), black

Product Status
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
Other
Connection
Other
With receiver
No
Measuring range
0 - 40 °C
External sensor
Yes
Differential value
0,10 - 1,00 k
Adjustable differential
Yes
Temperature readable
No
With sound indicator
No
Mounting method
Flush-mounted
Number of modules (module system)
1
With display
No
With tap water circuit
No
Degree of protection (IP)
IP40
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
Black
RAL-number
7021
Height
52,80 mm
Width
22,30 mm
Depth
49,70 mm
Diameter
0 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352685765
1 NR
6x4.5x5.4 [cm]
41.54 [g]
Barcode Qty 10 NR
8007352685772
10 NR
23.5x12.5x6.5 [cm]
498.75 [g]
Barcode Qty 90 NR
8007352741188
90 NR
37.5x30x21 [cm]
4,928.75 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
