Trop.KNX RFID outdoor reader whiteCode 30567.TRB

30567.TRB

Smart systems&products / KNX / LINEA / Devices

Trop.KNX RFID outdoor reader white

Tropicalised transponder card reader with vertical pocket for installation outside the room, KNX standard, 2 NO 4 A 24 V~ relay outputs, 2 inputs, 12-24 V~ 50- 60 Hz and 12-24 VDC (SELV) power supply, white - 3 modules. For indoor use. Supplied without transponder card

Product Status

2 - Will be discontinued

Alternative products

30565.TRB - Fuoriporta RFID KNXSecure trop.2M bianco

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Full Multilanguage instructions sheet (1432 kb)
• Light multilanguage instructions sheet (713 kb)
• Manuale installatore (1126 kb)
• Installer manual (961 kb)

Product Software

• DB_ControlloAccessi _KNX_REL-01.11_20260708.zip

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Installation bus systems

Class
Access control unit for bus system

Bus system KNX
Yes

Bus system KNX-RF (Radio Frequency)
No

Bus system radio frequency
No

Bus system LON
No

Bus system Powernet
No

Other bus systems
None

Model
Other

Mounting method
Flush-mounted

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9016

Transparent
No

Degree of protection (IP)
IP40

With bus connection
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352700697

1 NR

10.8x8.7x5.9 [cm]

78.2 [g]
