KNX dial thermostat 2M black - 30571.G

Pdf
Vimar - 30571.G - KNX dial thermostat 2M black
Vimar - 30571.G - KNX dial thermostat 2M black

30571.G
Smart systems&products / KNX / LINEA / Devices

KNX dial thermostat 2M black
Electronic dial thermostat for room temperature control (heating and air conditioning) of 2 independent zones, KNX standard home automation system, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, can be interfaced with actuator with KNX proportional analogue outputs to implement a class V modulating room thermostat (contribution 3%), 1 input for wired temperature sensor 02965.1, 1 programmable digital input, white LED backlighting, to be completed with cover plate, black - 2 modules

Product Status
3 - Active

Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
Other
Connection
2-wire
With receiver
No
Measuring range
0 - 40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
Yes
Number of cooler outputs
1
Differential value
0,10 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Max. contact voltage
29 V
Max. contact load
0 A
Degree of protection (IP)
IP20
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
Black
RAL-number
7021
Height
52,80 mm
Width
44,80 mm
Depth
41,70 mm
Diameter
0 mm
Class of the temperature control
V
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes

00. CE Marking - EU

27. KNX

37. Marking - Morocco

43. UKCA mark - Great Britain

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352689190
1 NR
6x5.4x5.2 [cm]
60 [g]
Barcode Qty 10 NR
8007352689206
10 NR
28.1x13.1x6 [cm]
690.4 [g]
Barcode Qty 120 NR
8007352689213
120 NR
38.5x29x30 [cm]
8,728 [g]
