IoT dial thermostat 2M canvas - 30810.C

Pdf
Vimar - 30810.C - IoT dial thermostat 2M canvas
Vimar - 30810.C - IoT dial thermostat 2M canvas

30810.C
Wiring devices / View Wireless wiring devices / LINEA / Devices

IoT dial thermostat 2M canvas
Dial thermostat with relay output 5(2) A 240 V~, IoT technology on Bluetooth technology 5.0 standard for the creation of VIEW Wireless mesh system, 1 input for external temperature sensor, 100-240 V~ 50/60 Hz power supply, heating and air conditioning in ON/OFF and PID mode, class I temperature control device (contribution 1%) in ON/OFF mode, class IV (contribution 2%) in PID mode, white LED backlighting with brightness control, canvas - 2 modules

  • It is compatible with voice assistants Alexa and Google Home through Skill and Action VIEW Product
  • Maximum simplicity thanks to the large knob
  • Configuration via “VIEW Wireless” App for Bluetooth technology system
  • Hotkeys are designed for quick interaction

Product Status
3 - Active

You may also be interested in

30807.C
30807.C - IoT connected Gateway 2M canvas
Class group
Stats, switches and controllers
Class
Room thermostat
Model
Other
Type of power supply
230 V AC
Connection
3-/4-wire
With receiver
No
Measuring range
0 - 40 °C
External sensor
Yes
Thermal feedback
Parallel
Control characteristic
PID
Suitable for heating
Yes
Number of heater outputs
1
Suitable for cooling
Yes
Number of cooler outputs
1
Differential value
0,10 - 1,00 k
Adjustable differential
Yes
Temperature readable
Yes
With sound indicator
No
Sensor/feeler type
Resistance sensor
Mounting method
Flush-mounted
Number of modules (module system)
2
With display
Yes
Operation
Turn
With tap water circuit
No
Contact type
Normally open contact (NO)
Max. contact voltage
230 V
Max. contact load
5 A
Degree of protection (IP)
IP20
Degree of protection (NEMA)
Other
Explosion-proof
No
Colour
Beige
RAL-number
7032
Height
52,80 mm
Width
44,80 mm
Depth
41,70 mm
Diameter
0 mm
Class of the temperature control
IV
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

46. UK PSTI compliance

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352691148
1 NR
6x5.4x5.2 [cm]
71.2 [g]
Barcode Qty 10 NR
8007352691155
10 NR
28.1x13.1x6 [cm]
800.8 [g]
Barcode Qty 120 NR
8007352691162
120 NR
38.5x29x30 [cm]
10,049 [g]

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
