Device XT KNX 1M blackCode 32121.G
- 32121.G
- Smart systems&products / KNX / LINEA / XT devices
- Device XT KNX 1M black
- Linea control device with XT platform, KNX standard with 2 push buttons, also configurable as 1 rocker button, LED with status function and visible in darkness with brightness control, central LED matrix to customise symbols or animation, black - 1 front module
- Product Status
- 3 - Active
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (1186 kb)
- Foglio istruzioni Full (887 kb)
- Notice technique Full (888 kb)
- Ficha de instrucciones Full (887 kb)
- Full instructions sheet (887 kb)
- Φυλλάδιο οδηγιών Full (1003 kb)
- Anweisungsblatt Full (887 kb)
- ورقة الإرشادات Full (925 kb)
- Manuale installatore (2922 kb)
- Installer manual (1901 kb)
Product Software
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Multi operating device for bus system
Multi operating device for bus system
Mounting method
Flush-mounted
Flush-mounted
Width in number of modular spacings
0
0
Number of actuation points
2
2
With display
No
No
Status-LED
Yes
Yes
IR sensor
No
No
Material
Plastic
Plastic
Material quality
Thermoplastic
Thermoplastic
Surface protection
Untreated
Untreated
Surface finishing
Matt
Matt
Colour
Black
Black
RAL-number (similar)
7021
7021
Transparent
No
No
Degree of protection (IP)
IP40
IP40
00. CE Marking - EU
37. Marking - Morocco
Minimum order quantity: 1 NR
Barcode
8007352736764
1 NR
11.5x6x1.7 [cm]
32.2 [g]
8007352736771
10 NR
13x9.4x12.6 [cm]
389.77 [g]
