Pinhole AHD cam 1080p 3,7mm - 46534.037BP

Download as PDF PDF Add to portfolio
Immagine 46534.037BP
download product photo

46534.037BP
Safety / ELVOX CCTV / AHD / Cameras

Pinhole AHD cam 1080p 3,7mm
Special pinhole camera, Full-HD 1080p resolution, 1/2.9in sensor, electronic IR filter, fixed 3.7 mm Pinhole lens, 0.001 lux sensitivity. Functions: 2-3DNR, D-WDR, BLC, HSBLC, Defog, CoC. 12 V DC 95 mA power supply. Dimensions 45x38.5x24mm. Weight 74 g.

Product Status
2 - Will be discontinued

Sheets, Manuals, Documentation

Class group
Alarm installations, emergency call and signalling
Class
Camera for surveillance system
Model
Standard (Fixed)
Construction type
Pin hole shape
Thermal camera
No
Number of pixels (Megapixel)
2
With lens
Yes
Modular (lens and camera separated)
No
Focal size
3,70 - 3,71 mm
Shutter control
DC
Lens connection
Other
Motor zoom
No
Suitable for wall mounting
Yes
Suitable for ceiling mounting
Yes
Suitable for corner mounting
No
Suitable for surface mounting
Yes
Flush-mounted installation/built-in installation
No
Suitable for outdoor use
No
Communication medium wired
Yes
Communication medium wireless
No
Type of interface
Other
Protocol
Other
Power over Ethernet (PoE)
None
Picture system
PAL
Frame rate
25
Property picture system
Colour
With infrared lighting
Yes
Max. infrared reach
0 m
With white light
No
Max. white light reach
0 m
Supports H.264 codec
No
Supports H.265 codec
No
Supports Motion JPEG codec
Yes
Supports MPEG-4 codec
No
With video motion detector
No
With integrated AI analysis
No
With slot for memory card
No
With memory card
No
Memory capacity
0
Number of digital inputs
0
Number of digital outputs
0
Number of audio inputs
0
Number of audio outputs
0
With integrated audio analysis
No
HDMI-connection
No
Mini HDMI-connection
No
VGA-connection (D-Sub 15-pole)
No
DVI-connection
No
BNC-connection
Yes
DisplayPort-connection
No
Mini DisplayPort
No
S-Video-connection
No
USB-C-connection
No
Vandal proof
No
Impact strength
Other
Degree of protection (IP)
Other
Horizontal field of view
67,00 - 67,10
With microphone
No
With loudspeaker
No
Power consumption
1,14 W
Supply voltage
0,10 - 12,01 V
Voltage type
DC
Colour
Black
Diameter
0,00 mm
Height
45,00 mm
Width
28,50 mm
Depth
24,00 mm
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Compatible with Amazon Alexa
No
IFTTT support available
No

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8013406309570
1 NR
12.5x12.5x9.4 [cm]
143 [g]
