1-chann.Balun video passive transducer - 46862.001.01

46862.001.01
Safety / ELVOX CCTV / AHD / Accessories

1-chann.Balun video passive transducer
Balun video passive transducer for video transmission on twisted pair, BNC connector for connection to the camera or DVR, screw connection for the cable

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (811 kb)

Class group
Data and telecommunication

Class
Balun

Application
Other

Connection 1
BNC

Connection type connection 1
Plug

Impedance connection 1
75 Ohm

Pin assignment connection 1
Other

Connection 2
Other

Connection type connection 2
Plug

Impedance connection 2
100 Ohm

Pin assignment connection 2
Other

Screened
Yes

Compatible with Grade2TV according to XP-C 90-483
No

Compatible with Grade3TV according to XP-C 90-483
No

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 4 NR

---

Barcode

8013406295651

1 NR

5x1.6x1.6 [cm]

14 [g]

8013406295965

4 NR

8x3.8x8.2 [cm]

96 [g]
