46862.A01.01
Safety / ELVOX CCTV / AHD / Accessories
1-chann.Balun video passive transducer
Balun video passive transducer for video transmission on twisted pair, BNC connector for 14 cm of cable for connection to the camera or DVR, screw connection for the cable
Product Status
3 - Active
Sheets, Manuals, Documentation
Class group
Installation material for data and telecommunication networks
Installation material for data and telecommunication networks
Class
Balun
Balun
Application
Other
Other
Connection 1
BNC
BNC
Connection type connection 1
Plug
Plug
Impedance connection 1
75 Ohm
75 Ohm
Pin assignment connection 1
Other
Other
Connection 2
Other
Other
Connection type connection 2
Plug
Plug
Impedance connection 2
100 Ohm
100 Ohm
Pin assignment connection 2
Other
Other
Screened
Yes
Yes
Compatible with Grade2TV according to XP-C 90-483
No
No
Compatible with Grade3TV according to XP-C 90-483
No
No
00. CE Marking - EU
Minimum order quantity: 4 NR
Barcode

8013406295668
1 NR
8x1.5x3 [cm]
24 [g]

8013406295972
4 NR
8x3.8x8.2 [cm]
115.6 [g]
