Video transducer Balun+power supp.2ch.2p - 46862.B01

46862.B01
Safety / ELVOX CCTV / AHD / Accessories

Video transducer Balun+power supp.2ch.2p
Pair of Balun video passive transducers (transmitter/receiver) for video transmission on twisted pair, BNC connector for the video, jack for the power supply, cable connection with RJ45 connector, maximum distance attainable with CAT5 cable 50 m, compatible with PAL/NSC/SECAM, built-in electrostatic discharge protection

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (661 kb)

Class group
Installation material for data and telecommunication networks

Class
Balun

Application
Other

Connection 1
BNC

Connection type connection 1
Plug

Impedance connection 1
75 Ohm

Pin assignment connection 1
Other

Connection 2
Other

Connection type connection 2
Plug

Impedance connection 2
100 Ohm

Pin assignment connection 2
Other

Screened
Yes

Compatible with Grade2TV according to XP-C 90-483
No

Compatible with Grade3TV according to XP-C 90-483
No

00. CE Marking - EU

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8013406261038

1 NR

8.4x8x3.8 [cm]

72.5 [g]
