EKKOART200D SLAVE operator 24V 2m 200kg - EAM6.N

EAM6.N

ELVOX Gates / Operators / Articulated swing

EKKOART200D SLAVE operator 24V 2m 200kg
Non-reversible 24 V SLAVE electromechanical operator with articulated arm for swing gates up to 2 m and 200 kg, complete with integrated mechanical opening and closing stops and fixing brackets

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Installer manual (6170 kb)

Class group
Gate operators, pumps and ventilators

Class
Swing gate operator

Model
One-wing, left and right

Max. width of door/gate wing
2.000 mm

Max. weight of door/gate leaf
200 kg

Drive principle
Electromechanical

Type of current
DC

Motor voltage
24 v

Limit switch
Internal end switch

With manual transmitter
No

With motor control unit
No

With post fittings
Yes

With wing fittings
Yes

With key-switch
No

With radio receiver
No

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8013406301413

1 NR

31.6x19.6x27.5 [cm]

8,000 [g]
