Flush consumer unit 8M Idea white - V53008.B

Pdf
Vimar - V53008.B - Flush consumer unit 8M Idea white
Vimar - V53008.B - Flush consumer unit 8M Idea white

V53008.B
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

Flush consumer unit 8M Idea white
Flush consumer unit with horizontally hinged transparent door, 8 modules, delivered with DIN (60715 TH35) rail, Idea white

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Small distribution board
Mounting method
Flush-mounted
Number of rows
1
Width in number of modular spacings
8
Type of covering
Door
Transparent cover/door
Yes
With lock
No
Housing material
Plastic
DIN-rail
Yes
With mounting plate
No
Extension possible
No
EMC-version
No
Colour
White
RAL-number
0
Degree of protection (IP)
IP40
Height
176,00 mm
Width
230,00 mm
Depth
18,00 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352081901
1 NR
28.4x18.4x7.5 [cm]
360.8 [g]
Barcode Qty 14 NR
8007352369177
14 NR
58x38.5x30 [cm]
5,851.02 [g]
