Flush consumer unit 12M met.anthracite - V53012.V23

Pdf
Vimar - V53012.V23 - Flush consumer unit 12M met.anthracite
Vimar - V53012.V23 - Flush consumer unit 12M met.anthracite

V53012.V23
System infrastructure / Enclosures and control units / Switchboards / Flush mounting

Flush consumer unit 12M met.anthracite
Flush consumer unit with horizontally hinged transparent door, 12 modules, delivered with DIN (60715 TH35) rail, metallized anthracite

Product Status
2 - Will be discontinued

Class group
Distribution boards
Class
Small distribution board
Mounting method
Flush-mounted
Number of rows
1
Width in number of modular spacings
12
Type of covering
Door
Transparent cover/door
Yes
With lock
No
Housing material
Plastic
DIN-rail
Yes
With mounting plate
No
Extension possible
No
EMC-version
No
Colour
Grey
RAL-number
0
Degree of protection (IP)
IP40
Height
176,00 mm
Width
302,00 mm
Depth
18,00 mm
Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352085879
1 NR
33.4x18.9x7.9 [cm]
477.07 [g]
