Flush mounting box for V53124 - V53324

Pdf
V53324

Consumer units / Flush mounting / Consumer units mounting boxes

Flush mounting box for V53124
Flush mounting box for 24-module consumer unit (GW 650 °C) for masonry walls, light blue. Dimensions 316x423x80 mm

Product Status
3 - Active

Class group
Distribution boards
Class
Empty cabinet
Mounting method
Flush mounted (plaster)
Type of cover
None
Cover model
None
Type of door
None
Transparent cover/door
No
With lock
No
Nominal current (In)
0 A
Height
423 mm
Width
316 mm
Depth
80,00 mm
Built-in depth
80,00 mm
Internal depth
78,00 mm
RAL-number
0
Number of modules
24
Number of rows
2
Width in number of modular spacings
24
Number of openings for flange plates
0
Extension possible
No
Number of conduit inlets
14
Material housing
Plastic
Surface protection
Untreated
With mounting plate
No
Suitable for outdoor use
No
Suitable for lightning protection
No
Degree of protection (IP)
IP40
Protection class
II
Circuit integrity
None
Minimum order quantity: 7 NR

Barcode

Barcode Qty 1 NR
8007352509917
1 NR
31.6x42x8 [cm]
708 [g]
Barcode Qty 7 NR
8007352509924
7 NR
58x38x42.5 [cm]
5,500 [g]
