4-channel AHD DVR 1080p - 46540.F04

Pdf

46540.F04
Safety / ELVOX CCTV / AHD / DVR

4-channel AHD DVR 1080p
DVR with 4+1 channels AHD/IP/CVBS compatible with 1 additional IP video camera, professional HDD 1TB, Pentaplex, H.264, CsC function, supports AHD up to 1080P (Full-HD @ 25fps) and IP up to 2 Mpx (Full-HD @ 25 fps), 4 in/1 out audio outputs, 4 in/1 out alarm management outputs, RS485 port, 2 USB, BNC outputs (CVBS only), VGA and HDMI up to Full HD, Ethernet RJ45, privacy masking, motion, web interface, CVM, remote control and QRCODE. 12 Vdc power supply unit included. Dimensions 300x248x52 mm.

Product Status
9 - Discontinued

Share

Codice QR scheda articolo

Legal

Vimar reserves the right to change at any time and without notice the characteristics of the products reported. Installation should be carried out by qualified staff in compliance with the current regulations regarding the installation of electrical equipment in the country where the products are installed. For the terms of use of the information on the product info sheet see Conditions of Use.
