LED lamp 120-230 Arké/Plana 7M - 02670.1

02670.1
Wiring devices / Traditional wiring devices / Shared components / Devices

LED lamp 120-230 Arké/Plana 7M
Lighting device with high-efficiency LED, supply voltage 120-230 V~ 50-60 Hz, built-in mounting frame for 6/7-module flush mounting boxes. To complete with Arké or Plana cover plates

Product Status
2 - Will be discontinued

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Sheets, Manuals, Documentation

• Multilanguage instructions sheet (827 kb)

---

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Information light signal for domestic switching devices

Number of modules (module system)
7

With light source
Yes

Lamp type
LED not exchangeable

With flashlight
No

Mounting method
Flush-mounted

Type of fastening
Screw mounting

Material
Plastic

Material quality
Thermoplastic

Surface protection
Untreated

Surface finishing
Matt

Colour
White

RAL-number (similar)
9003

Transparent
No

Colour light source
White

Suitable for degree of protection (IP)
IP40

Nominal voltage
230 V

Max. lamp power
3 W

00. CE Marking - EU

37. Marking - Morocco

43. UKCA mark - Great Britain

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352442863

1 NR

21.4x6.6x9.3 [cm]

228.1 [g]
