Actuator 0/1-10Vdc + IoT connected relayCode 03986
- 03986
- Wiring devices / View Wireless wiring devices / Shared components / DIN devices
- Actuator 0/1-10Vdc + IoT connected relay
- VIEW Wireless electronic control actuator with 1 proportional analogue 0/1-10 V output with re-scalable voltage, 1 10 AX relay output 100-240 V~ 50/60 Hz, programmable NO/NC with function to control lights, fan coil, climate control, accesses, IoT technology on Bluetooth 5.0 standard for the creation of VIEW Wireless mesh system, 100-240 V 50/60 Hz power supply, installation on DIN rail (60715 TH35), occupies 2 modules size 17.5 mm
- Product Status
- 3 - Active
You may also be interested in
Sheets, Manuals, Documentation
- Light multilanguage instructions sheet (958 kb)
- Notice technique Full (594 kb)
- Ficha de instrucciones Full (594 kb)
- Full instructions sheet (591 kb)
- Φυλλάδιο οδηγιών Full (718 kb)
- Anweisungsblatt Full (594 kb)
- ورقة الإرشادات Full (725 kb)
- Foglio istruzioni Full (595 kb)
- Manuale app View Wireless (19693 kb)
- Manuel appli View Wireless (43543 kb)
- Manual app View Wireless (43542 kb)
- Manual View Wireless app (42589 kb)
- Εγχειρίδιο τεχνικού εγκατάστασης (43825 kb)
- Installationsanleitung View Wireless (43598 kb)
Drawings
Class group
Installation bus systems
Installation bus systems
Class
Dimming actuator for bus system
Dimming actuator for bus system
Bus system KNX
No
No
Bus system KNX-RF (Radio Frequency)
No
No
Bus system radio frequency
Yes
Yes
Bus system LON
No
No
Bus system Powernet
No
No
Other bus systems
Other
Other
Radio frequency bidirectional
Yes
Yes
Model
Dimming actuator
Dimming actuator
Mounting method
Other
Other
Width in number of modular spacings
2
2
Local operation/hand operation
Yes
Yes
With LED indication
Yes
Yes
Number of outputs
2
2
Type of load
Universal
Universal
Max. control current
10.000 mA
10.000 mA
Degree of protection (IP)
IP40
IP40
01. IMQ - Italy
37. Marking - Morocco
40. Bluetooth technology
Minimum order quantity: 1 NR
Barcode
8007352767430
1 NR
14.2x6.2x5.6 [cm]
134 [g]
8007352767447
40 NR
37x28.5x25 [cm]
5,700 [g]
