TV-RD-SAT single conn.male outlet 1dB - 08190.01

08190.01
Wiring devices / Traditional wiring devices / 8000 / Devices

TV-RD-SAT single conn.male outlet 1dB
Coaxial TV-RD-SAT 5-2400 MHz socket outlet single connection, with IEC 60169-2 male connector, connection attenuation 1 dB. Allows the passage of d.c. current and control signals (24 V 500 mA max).

Product Status
3 - Active

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Antenna and satellite technique

Class
Antenna socket box

Model
End socket

Cover
None

Tap loss at 860 MHz
0,10 dB

Tap loss at 2150 MHz
0,20 dB

Number of outlets
1

Suitable for remote power supply
Yes

Type of fastening
Snap mounting (engagement)

Colour
Beige

RAL-number (similar)
9001

Material
Plastic

00. CE Marking - EU

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 20 NR

---

Barcode

8007352100992

1 NR

4.1x2.8x5.3 [cm]

39.9 [g]

8007352101005

20 NR

21.4x11.6x6 [cm]

862.8 [g]

8007352641495

200 NR

30.5x25.5x22.5 [cm]

9,260 [g]
