1P 16AX 1-way switch carbon matt - 09001.CM

Pdf
Vimar - 09001.CM - 1P 16AX 1-way switch carbon matt
Vimar - 09001.CM - 1P 16AX 1-way switch carbon matt

09001.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P 16AX 1-way switch carbon matt
1P 1-way switch 16 AX 250 V~, Carbon Matt. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

You may also be interested in

09001.2.CM
09001.2.CM - 1P 16AX 1-way switch 2M carbon matt
09015.CM
09015.CM - 2P 16AX 1-way switch carbon matt
09005.CM
09005.CM - 1P 16AX 2-way switch carbon matt
09013.CM
09013.CM - 1P 16AX reversing switch carbon matt
09008.CM
09008.CM - 1P NO 10A push button carbon matt

Drawings

view encumbered art. 09001.CM
PNG DXF
rear view art. 09001.CM
PNG DXF
3D view art. 09001.CM
PNG DXF
Class group
Domestic switching devices
Class
Installation switch
Wiring system
Off switch 1-pole
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Label space/information surface
Yes
Nominal voltage
250 V
Rated current
16,00 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
No
Device width
22,30 mm
Device height
47,00 mm
Device depth
35,90 mm
Built-in depth
23,10 mm

00. CE Marking - EU

13. SNI-MGI - Indonesia

15. CCC - China

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352657649
1 NR
4.1x2.8x5.3 [cm]
23.2 [g]
Barcode Qty 50 NR
8007352657656
50 NR
21.4x11.6x14.2 [cm]
1,244.8 [g]
Barcode Qty 500 NR
8007352657663
500 NR
57.5x22.5x30 [cm]
12,702 [g]
