1P NO 10A 2M push button carbon matt - 09008.2.CM

Pdf
Vimar - 09008.2.CM - 1P NO 10A 2M push button carbon matt
Vimar - 09008.2.CM - 1P NO 10A 2M push button carbon matt

09008.2.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

1P NO 10A 2M push button carbon matt
1P NO 10 A 250 V~ push button, Carbon Matt - 2 modules

Product Status
3 - Active

You may also be interested in

09008.CM
09008.CM - 1P NO 10A push button carbon matt
09001.2.CM
09001.2.CM - 1P 16AX 1-way switch 2M carbon matt
09005.2.CM
09005.2.CM - 1P 16AX 2-way switch 2M carbon matt
09013.2.CM
09013.2.CM - 1P 16AX reversing switch 2M carbon matt
09050
09050 - 1P NO 10A name-plate push button white

Drawings

view encumbered art. 09008.2.CM
PNG DXF
rear view art. 09008.2.CM
PNG DXF
3D view art. 09008.2.CM
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Single push button
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
200
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Device width
44,90 mm
Device height
47,00 mm
Device depth
35,90 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352658103
1 NR
5.1x4.3x5.3 [cm]
30.8 [g]
Barcode Qty 20 NR
8007352658110
20 NR
26.9x11.6x9 [cm]
698.8 [g]
Barcode Qty 240 NR
8007352658127
240 NR
38x28.5x35.5 [cm]
8,927.6 [g]
