Two interlocked 1P NO+NO 10A pushes carb - 09062.CM

Pdf
Vimar - 09062.CM - Two interlocked 1P NO+NO 10A pushes carb
Vimar - 09062.CM - Two interlocked 1P NO+NO 10A pushes carb

09062.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Two interlocked 1P NO+NO 10A pushes carb
Two interlocked 1P NO + 1P NO 10 A 250 V~ buttons, with directional arrows, carbon matt

Product Status
3 - Active

You may also be interested in

09060.CM
09060.CM - 2P 10AX switch carbon matt

Drawings

view encumbered art. 09062.CM
PNG DXF
rear view art. 09062.CM
PNG DXF
3D view art. 09062.CM
PNG DXF
Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
1
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Anti-bacterial treatment
No
Surface protection
Untreated
Surface finishing
Glossy
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No
Label space/information surface
Yes
Device width
22,30 mm
Device height
47,00 mm
Device depth
38,50 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

13. SNI - Indonesia

15. CCC - China

29. QCERT - Colombia

29. QCERT - Colombia

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352665828
1 NR
4.1x2.8x5.3 [cm]
32 [g]
Barcode Qty 20 NR
8007352665835
20 NR
21.4x11.6x6 [cm]
694.2 [g]
Barcode Qty 200 NR
8007352665842
200 NR
30.5x25.5x22.5 [cm]
7,284 [g]
