Shaver supply unit 230V carbon matt - 09290.CM

09290.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

Shaver supply unit 230V carbon matt
Shaver socket outlet with 20 VA insulation transformer, 230 V~ 50-60 Hz power supply, 120 V~ output for 2P 15 A 125 V~ American standard non-polarised flat pin plugs and 230 V~ output for 2P 2.5 A europlugs, with built-in mounting frame, carbon matt - 3 modules

Product Status
3 - Active

You may also be interested in

09470.CM - Dial thermostat 100-240V 2M carbon m

09026.PLS.CM - Button 1M +diffuser PLS symb.carbon matt

09026.DND.CM - Button 1M +diffuser DND symb. carbon m

09463.CM - Vertical badge switch 2M carbon matt

09465.CM - Vertical pocket badge switch carbon matt

09257.CM - 2P+E13ASICURY multistandard outlet carbo

09052.CM - 1P NO 10A cord-operated push carbon matt

09181.CM - IR relay-switch 230V carbon matt

• Documents and downloads
• ETIM technical data
• Certifications
• Supply data

Drawings

PNG DXF

PNG DXF

PNG DXF

Class group
Domestic switching devices

Class
Razor socket outlet

Assembly arrangement
Modular device for domestic switching devices

Number of modules (module system)
3

Mounting method
Flush-mounted

With hinged lid
No

Voltage reversible
No

Nominal voltage low value
230 V

Nominal voltage high value
230 V

Material
Plastic

Material quality
Thermoplastic

Surface protection
Lacquered

Surface finishing
Matt

Colour
Anthracite

RAL-number (similar)
7016

Transparent
No

Device width
118,00 mm

Device height
65,00 mm

Device depth
56,40 mm

With built-in installation box
No

00. CE Marking - EU

37. Marking - Morocco

37. Marking - Morocco

99. WEEE Directive

Minimum order quantity: 1 NR

---

Barcode

8007352665712

1 NR

13x8.6x6.85 [cm]

489.24 [g]
