IR relay-switch 230V carbon matt - 09181.CM

Pdf
Vimar - 09181.CM - IR relay-switch 230V carbon matt
Vimar - 09181.CM - IR relay-switch 230V carbon matt

09181.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

IR relay-switch 230V carbon matt
1-way switch with infrared motion sensor for switching on lights, adjusTable dusk/dawn sensor threshold and timer cycle, NO 6 A 230 V~ relay output, 230 V~ 50-60 Hz power supply, carbon matt

Product Status
3 - Active

You may also be interested in

09026.PLS.CM
09026.PLS.CM - Button 1M +diffuser PLS symb.carbon matt
09026.DND.CM
09026.DND.CM - Button 1M +diffuser DND symb. carbon m
09097
09097 - Pushbutton +2 Hotel indicators 230V
09470.CM
09470.CM - Dial thermostat 100-240V 2M carbon m
09290.CM
09290.CM - Shaver supply unit 230V carbon matt
09463.CM
09463.CM - Vertical badge switch 2M carbon matt
09465.CM
09465.CM - Vertical pocket badge switch carbon matt
09257.CM
09257.CM - 2P+E13ASICURY multistandard outlet carbo
09052.CM
09052.CM - 1P NO 10A cord-operated push carbon matt

Sheets, Manuals, Documentation

Drawings

view encumbered art. 09181.CM
PNG DXF
rear view art. 09181.CM
PNG DXF
3D view art. 09181.CM
PNG DXF
Class group
Domestic switching devices
Class
Electronic insert for domestic switching devices
Model
Other
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Radio-controlled
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Transparent
No

00. CE Marking - EU

37. Marking - Morocco

37. Marking - Morocco

43. UKCA mark - Great Britain

99. WEEE Directive

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352664463
1 NR
5.1x4.3x5.3 [cm]
53.07 [g]
Barcode Qty 5 NR
8007352664470
5 NR
14.4x11.6x6 [cm]
315.13 [g]
Barcode Qty 60 NR
8007352664487
60 NR
36.5x33x13.5 [cm]
4,578 [g]
