C+C-USB supply unit 15W3A5V 1M carbon m - 09292.CC.CM

Pdf

09292.CC.CM
Wiring devices / Traditional wiring devices / NEVE UP / Devices

C+C-USB supply unit 15W3A5V 1M carbon m

Product Status
3 - Active

Sheets, Manuals, Documentation


Drawings

Class group
Domestic switching devices
Class
USB power supply
Model
Bus
Operating voltage
100,00 - 240,00 V
Frequency
50,00 - 60,00 HZ
Max. output current
3.000 mA
Connection type
Screwed terminal
Mounting method
Flush-mounted
Colour
Anthracite
RAL-number
7016
Device width
22,30 mm
Device height
47,00 mm
Device depth
46,50 mm
Min. depth of built-in installation box
42 mm
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Anti-bacterial treatment
No

00. CE Marking - EU

00. CE Marking - EU

37. Marking - Morocco

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352728806
1 NR
5.2x3.5x5.3 [cm]
52 [g]
Barcode Qty 10 NR
8007352728813
10 NR
14.4x13.1x6 [cm]
518.62 [g]
Barcode Qty 60 NR
8007352765887
60 NR
27x23x12.5 [cm]
3,310 [g]
Barcode Qty 200 NR
8007352728820
200 NR
50.5x20x28 [cm]
10,372 [g]
