Connected 2-way switch 2M carbon matt - 09592.2.CM

Pdf
Vimar - 09592.2.CM - Connected 2-way switch 2M carbon matt
Vimar - 09592.2.CM - Connected 2-way switch 2M carbon matt

09592.2.CM
Wiring devices / View Wireless wiring devices / NEVE UP / Devices

Connected 2-way switch 2M carbon matt

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
Two-way switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
2
Push button switch
Yes
Number of rockers
1
Mounting method
Built-in installation
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Anti-bacterial treatment
No
Surface protection
Lacquered
Surface finishing
Matt
Colour
Anthracite
RAL-number (similar)
7016
Label space/information surface
No
Illumination
Yes
Function lighting
Illuminated (on)
Type of lighting
LED not exchangeable
Suitable for degree of protection (IP)
IP40
Impact strength
Not available
Nominal voltage
240 V
Rated current
0,00 A
Switching current for fluorescent lamps
0
Feedback-signal contact
No
Connection type
Screwed terminal
Heating switch
No
Washing machine switch
No
Device width
44,80 mm
Device height
47,00 mm
Device depth
51,20 mm
Built-in depth
37,90 mm
Min. depth of built-in installation box
40,00 mm
Compatible with Apple HomeKit
Yes
Compatible with Google Assistant
Yes
Compatible with Amazon Alexa
Yes
IFTTT support available
Yes

00. CE Marking - EU

37. Marking - Morocco

40. Bluetooth technology

42. Zigbee certified

43. UKCA mark - Great Britain

46. UK PSTI compliance

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 1 NR

Barcode

Barcode Qty 1 NR
8007352732209
1 NR
6x5.4x5.2 [cm]
59 [g]
Barcode Qty 60 NR
8007352732216
60 NR
37.5x30x13.5 [cm]
3,844 [g]
