2P 16AX 1-way switch Silver - 14015.SL

Pdf
Vimar - 14015.SL - 2P 16AX 1-way switch Silver
Foto gallery #1
Foto gallery #2
Vimar - 14015.SL - 2P 16AX 1-way switch Silver
14015.SL

Plana Silver / Devices / Basic devices

2P 16AX 1-way switch Silver
2P 16 AX 250 V~ 1-way switch, lightable, replaceable button, Silver. Max 200 W for self-ballasted lamps (IEC 60669-1:2017)

Product Status
3 - Active

Class group
Domestic switching devices
Class
Installation switch
Wiring system
2-pole switch
Method of operation
Rocker/button
Assembly arrangement
Modular device for domestic switching devices
Number of modules (module system)
1
Push button switch
Yes
Number of rockers
1
Mounting method
Flush mounted (plaster)
Type of fastening
Engage (snap)
With mounting plate
No
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Glossy
Colour
Silver
RAL-number (similar)
9006
Label space/information surface
Yes
Illumination
Optional
Function lighting
Control and orientation
Type of lighting
LED exchangeable
Suitable for degree of protection (IP)
IP40
Nominal voltage
250 v
Rated current
16 A
Feedback-signal contact
No
Connection type
Screwed terminal
Washing machine switch
Yes
Width of device
22,30 mm
Height of device
49,00 mm
Depth of device
38,70 mm
Built-in depth
24,00 mm

00. CE Marking - EU

01. IMQ - Italy

10. EAC Eurasian Customs Union

13. SNI - Indonesia

14. TSE - Turkey

15. CCC - China

19. NOM - Mexico

28. NSW / RCM - Australia

29. QCERT - Colombia

31. TISI - Thailand

37. Marking - Morocco

92. RoHS UAE

96. Electrotechnical expert

99. WEEE Directive

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352320277
1 NR
4.1x2.8x5.3 [cm]
31.2 [g]
Barcode Qty 50 NR
8007352320284
50 NR
21.6x11.6x14.3 [cm]
1,672 [g]
Barcode Qty 500 NR
8007352482807
500 NR
57.5x22.5x30 [cm]
17,870 [g]
