2P+E16A DE SICURY outlet screwless white - 14208.FX

Pdf
14208.FX

Plana / Devices / Other standards socket outlets

2P+E16A DE SICURY outlet screwless white
2P+E 16 A 250 V~ SICURY socket outlet, German standard, screwless terminals, white - 2 modules

Product Status
3 - Active

Class group
Domestic switching devices
Class
Socket outlet
Model
Protective contact (SCHUKO)
With built-in USB power supply
No
Number of modules (module system)
2
Number of socket outlets switchable
0
Imprint/indication
None
Connection type
Push-in clamp
With hinged lid
No
With enhanced contact protection
Yes
Label space/information surface
Yes
Colour
White
RAL-number (similar)
9003
Metallic colour
No
Transparent
No
Lockable
No
Eject-mechanism
No
Insulated mounting
No
With function lighting
No
Over voltage protection
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
With on/off switch
No
With loop through function
No
Rotated central insert
No
Nominal current
16 A
Nominal voltage
250 v
Frequency
50,00 - 60,00 HZ
Suitable for degree of protection (IP)
IP20
Impact strength
Other
Width of device
44,80 mm
Height of device
49,00 mm
Depth of device
38,90 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

37. Marking - Morocco

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352513020
1 NR
5x4.7x5.1 [cm]
55 [g]
Barcode Qty 20 NR
8007352513037
20 NR
26.4x11x10.9 [cm]
1,100 [g]
Barcode Qty 240 NR
8007352513044
240 NR
54.5x36x23.5 [cm]
13,804 [g]
