Antibacterial RJ11 phone jack 6/4 - 14320.AB

Pdf

14320.AB
Wiring devices / Traditional wiring devices / PLANA / Devices

Antibacterial RJ11 phone jack 6/4
RJ11 phone jack, 6-position 4-conductor (6/4), screw terminals, with antibacterial treatment, white

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Insert/cover for communication technology
Assembly arrangement
Modular device for domestic switching devices
Utilization
UAE/IAE (ISDN)
Support ring
No
With dust cover
No
With hinged lid
No
With imprint
No
Mounting method
Flush-mounted
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Untreated
Surface finishing
Glossy
Colour
White
RAL-number (similar)
9003
Transparent
No
Type of fastening
Clamp mounting
Number of modules (module system)
1
With strain relief
No
Luster terminal
No
Suitable for degree of protection (IP)
IP20
Device width
22,30 mm
Device height
49,00 mm
Device depth
43,10 mm

00. CE Marking - EU

Minimum order quantity: 20 NR

Barcode

Barcode Qty 1 NR
8007352499553
1 NR
5.1x2.8x5.3 [cm]
22.6 [g]
Barcode Qty 20 NR
8007352499560
20 NR
27x11.6x6 [cm]
519.2 [g]
