Frame 2M +claws 71mm grey - 14602.G

Pdf

14602.G
Wiring devices / Traditional wiring devices / PLANA / Mounting frames

Frame 2M +claws 71mm grey
2-module mounting frame, with claws, for ø 60 mm mounting boxes, modular, distance between centres 71 mm, grey

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Holder for modular domestic switching devices
Model
Flush-mounted
Mounting method
Mounting with claw
Mounting method of the module inserts
Front side
Mounting direction
Horizontal and vertical
Number of modules horizontal (module system)
2
Number of modules vertical (module system)
1
With built-in installation box
No
With screws
No
Suitable for mounting in round junction box 60 mm
Yes
Flush-mounted installation
Yes
Suitable for subfloor installation duct box
No
Suitable for wall duct
No
Suitable for mounting on DIN-rail 35 mm
No
Material
Plastic
Material quality
Thermoplastic

00. CE Marking - EU

29. QCERT - Colombia

Minimum order quantity: 50 NR

Barcode

Barcode Qty 1 NR
8007352136953
1 NR
7.4x7.4x1.5 [cm]
21.47 [g]
Barcode Qty 50 NR
8007352136960
50 NR
28.4x24.4x11.9 [cm]
1,235.6 [g]
Barcode Qty 300 NR
8007352649316
300 NR
59.5x38.5x26.5 [cm]
8,130 [g]
