Button 1M customizable Next - 20031.N

Pdf
Vimar - 20031.N - Button 1M customizable Next
Vimar - 20031.N - Button 1M customizable Next
20031.N

Eikon Next / Devices / Basic devices

Button 1M customizable Next
Interchangeable 1-module button, customizable on request with lightable symbol, Next

Product Status
3 - Active

Drawings

view encumbered art. 20031.N
PNG DXF
rear view art. 20031.N
PNG DXF
3D view art. 20031.N
PNG DXF
Class group
Domestic switching devices
Class
Control element/cover plate for domestic switching devices
Model
Single rocker
Imprint/indication
Label space
Utilization
Switch/push button
Suitable for touch sensor connector for bus system
No
Type of fastening
Clamp mounting
Monitoring window/light outlet
Yes
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
With label area
No
With exchangeable lens/symbol
No
Suitable for degree of protection (IP)
IP40
Depth
600 mm

01. IMQ - Italy

29. QCERT - Colombia

96. Electrotechnical expert

Minimum order quantity: 5 NR

Barcode

Barcode Qty 1 NR
8007352284968
1 NR
2.2x4.4x0.6 [cm]
2.67 [g]
Barcode Qty 5 NR
8007352284975
5 NR
4.1x2.8x5.3 [cm]
16.73 [g]
Barcode Qty 50 NR
8007352731028
50 NR
14.4x9x6 [cm]
167.3 [g]
Barcode Qty 750 NR
8007352284982
750 NR
28.4x24.4x16.4 [cm]
2,430 [g]
