Two independent NO+NO 10A pushes Next - 20066.N

Pdf

20066.N
Wiring devices / Traditional wiring devices / EIKON / Devices

Two independent NO+NO 10A pushes Next
Two independent push buttons, 1P NO + 1P NO 10 A 250 V~, Next. They allow the simultaneous closing of the two circuits and are thus not suitable for reversing motors (roller blinds, gates, etc.)

Product Status
3 - Active

Drawings

Class group
Domestic switching devices
Class
Push button
Assembly arrangement
Modular device for domestic switching devices
Model
Other
Method of operation
Push button
Number of rockers
2
Number of modules (module system)
100
Number of poles
1
Nominal voltage
250 V
Rated current
10,00 A
With lighting
No
Feedback-signal contact
No
Mounting method
Flush-mounted
Type of fastening
Engage (snap)
Material
Plastic
Material quality
Thermoplastic
Halogen free
Yes
Surface protection
Lacquered
Surface finishing
Matt
Colour
Silver
RAL-number (similar)
9022
Transparent
No
Label space/information surface
Yes
Suitable for degree of protection (IP)
IP40
Device width
22,30 mm
Device height
49,00 mm
Device depth
39,00 mm

00. CE Marking - EU

10. EAC Eurasian Customs Union

19. NOM - Mexico

20. IQC - Argentina

29. QCERT - Colombia

31. TISI - Thailand

36. ISI - India

37. Marking - Morocco

43. UKCA mark - Great Britain

92. RoHS UAE

Minimum order quantity: 10 NR

Barcode

Barcode Qty 1 NR
8007352291553
1 NR
4.1x2.8x5.3 [cm]
33.2 [g]
Barcode Qty 10 NR
8007352291560
10 NR
14.4x9x6 [cm]
366.87 [g]
Barcode Qty 160 NR
8007352637504
160 NR
37.5x30x13.5 [cm]
6,170.4 [g]
Question: Is it possible to interface the Vimar Due Fili 20557 doorbell with normal buttons?
Answer: Yes, you can connect buttons 20066-20557 with appropriate connection cables.
